| CPU-specificaties |
| Totaal aantal cores |
20 |
| Aantal prestatie-cores |
8 |
| Aantal efficiënte cores |
12 |
| Totaal aantal threads |
20 |
| Maximale turbofrequentie |
5.5 GHz |
| Intel® Turbo Boost Max Technology 3.0 Frequentie |
5.5 GHz |
| Maximale turbofrequentie prestatie-core |
5.4 GHz |
| Maximale turbofrequentie prestatie-core |
4.6 GHz |
| Basisfrequentie prestatie-core |
3.9 GHz |
| Basisfrequentie efficiënte core |
3.3 GHz |
| Cache |
30 MB Intel® Smart Cache |
| Totale L2-cache |
36 MB |
| Basisvermogen processor |
125 W |
| Maximale turbokracht |
250 W |
| Intel® Deep Learning Boost (Intel® DL Boost) op CPU |
✔ |
| AI-softwareframeworks ondersteund door CPU |
OpenVINO™ | WindowsML | DirectML | ONNX RT | WebNN |
| CPU-lithografie |
TSMC N3B |
| Geheugenspecificaties |
| Maximale geheugengrootte (afhankelijk van geheugentype) |
192 GB |
| Geheugentypen |
Tot en met DDR5 6400 MT/s |
| Maximale geheugen Snelheid |
6400 MHz |
| Max. aantal geheugenkanalen |
2 |
| ECC-geheugen ondersteund |
✔ |
| GPU-specificaties |
| GPU-naam‡ |
Intel® Graphics |
| Grafische basisfrequentie |
300 MHz |
| Grafische maximale dynamische frequentie |
2 GHz |
| GPU Peak TOPS (Int8) |
8 |
| Grafische uitvoer |
DP2.1 UHBR20 | HDM2.1 FRL 12GHz | eDP1.4b |
| Xe-cores |
4 |
| Max. resolutie (HDMI) |
4K @ 60Hz (HDMI 2.1 TMDS) 8K @ 60Hz (HDMI2.1 FRL) |
| Max. resolutie (DP) |
8K @ 60Hz |
| Max. resolutie (eDP - geïntegreerd plat paneel) |
4K @ 60Hz |
| DirectX*-ondersteuning |
12 |
| OpenGL*-ondersteuning |
4.5 |
| OpenCL*-ondersteuning |
3 |
| Intel® Quick Sync-video |
✔ |
| Aantal ondersteunde beeldschermen |
4 |
| Apparaat-ID |
0x7D67 |
| Intel® Deep Learning Boost (Intel® DL Boost) op GPU |
✔ |
| NPU-specificaties |
| NPU-naam |
Intel® AI Boost |
| NPU Peak TOPS (Int8) |
13 |
| Sparsity-ondersteuning |
✔ |
| Windows Studio Effects-ondersteuning |
✔ |
| AI-softwareframeworks ondersteund door NPU |
OpenVINO™ | WindowsML | DirectML | ONNX RT | WebNN |
| Uitbreidingsopties |
| Direct Media Interface (DMI)-revisie |
4 |
| Max. aantal DMI-lanes |
8 |
| Intel® Thunderbolt™ 4 |
✔ |
| Schaalbaarheid |
1S Only |
| PCI Express-revisie |
5.0 en 4.0 |
| PCI Express-configuraties |
Tot en met 1x16+2x4 | 2x8+2x4 | 1x8+4x4 |
| Max. aantal PCI Express-lanes |
24 |
| Pakketspecificaties |
| Ondersteunde sockets |
FCLGA1851 |
| Specificatie thermische oplossing |
PCG 2020A |
| Max. bedrijfstemperatuur |
105 °C |
| Geavanceerde technologieën |
| Intel® Volume Management Device (VMD) |
✔ |
| Intel® Gaussian & Neural Accelerator |
3.5 |
| Intel® Thread Director |
✔ |
| Intel® Speed Shift-technologie |
✔ |
| Intel® Turbo Boost Max-technologie 3.0 |
✔ |
| Intel® Turbo Boost-technologie |
2.0 |
| Intel® 64 |
✔ |
| Instructieset |
64-bit |
| Uitbreidingen instructieset |
Intel® SSE4.1 | Intel® SSE4.2 | Intel® AVX2 |
| Inactieve toestanden |
✔ |
| Verbeterde Intel SpeedStep®-technologie |
✔ |
| Thermische bewakingstechnologieën |
✔ |
| Beveiliging en betrouwbaarheid |
| Intel vPro®-geschiktheid |
Intel vPro® Enterprise | Intel vPro® Platform |
| Intel® Threat Detection Technology (TDT) |
✔ |
| Intel® Active Management Technology (AMT) |
✔ |
| Intel® Standard Manageability (ISM) |
✔ |
| Intel® Remote Platform Erase (RPE) |
✔ |
| Intel® One-Click Recovery |
✔ |
| Intel® Hardware Shield-geschiktheid |
✔ |
| Intel® Control-Flow Enforcement-technologie |
✔ |
| Intel® Total Memory Encryption - Multi Key |
✔ |
| Intel® AES Nieuwe instructies |
✔ |
| Beveiligde sleutel |
✔ |
| Intel® Trusted Execution-technologie |
✔ |
| Execute Disable Bit |
✔ |
| Intel® OS Guard |
✔ |
| Intel® Boot Guard |
✔ |
| Mode-based Execute Control (MBEC) |
✔ |
| Intel® Stable IT Platform Program (SIPP) |
✔ |
| Intel® Virtualisatietechnologie met Redirect Protection (VT-rp) |
✔ |
| Intel® Virtualisatietechnologie (VT-x) |
✔ |
| Intel® Virtualisatietechnologie voor Directed I/O (VT-d) |
✔ |
| Intel® VT-x met Extended Page Tables (EPT) |
✔ |
|
| Overige informatie |
| SKU |
BX80768265K |
| EAN |
5032037282062 |
|
| Doos inhoud |
| Intel Core Ultra 7 265K CPU (Processor) |
